Belt Filter Presses(TDR Series)

(Conditioning + drum thickening + double filter belt)

Spe.			TDR-500	TDR-750	TDR-1000
Spe.			Modei
Belt width (mm)			500	750	1000
Capacity (m³ /hr) Influent concentration (S.S 1.5~2.5%)			1.2~2.5	2.0~3.8	2.5~5.0
Absolute dryness D.S. (kg/hr)			18~37.5	30~57	38~75
Power usage (HP)	Belt driver (constant speed)		1/2	1/2	1/2
	Conditioning mixer		1/4	1/4	1/4
	Drum thickener		1/4	1/4	1/4
Machine material	Standard		Stainless steel SUS304
Machine material	Optional		Stainless steel SUS316 / 316L
Reference machine dimensions(mm)		L	1900	2050	2300
		W	1050	1300	1550
		H	2420	2420	2420
Reference weight (kgs)			430	520	610
