Inclined plate type rapid sedimentation tank

Inclined plate type rapid sedimentation tank(DAT-5) Type: DAT-5 Inclined plate type rapid sedimentation tank	Inclined plate type rapid sedimentation tank(DAT-10) Type: DAT-10 Inclined plate type rapid sedimentation tank	Inclined plate type rapid sedimentation tank(DAT-20) Type: DAT-20 Inclined plate type rapid sedimentation tank	Inclined plate type rapid sedimentation tank(DAT-35) Type: DAT-35 Inclined plate type rapid sedimentation tank
Inclined plate type rapid sedimentation tank(DAT-50) Type: DAT-50 Inclined plate type rapid sedimentation tank	Inclined plate type rapid sedimentation tank(DAT-75) Type: DAT-75 Inclined plate type rapid sedimentation tank	Inclined plate type rapid sedimentation tank(DAT-100) Type: DAT-100 Inclined plate type rapid sedimentation tank	Inclined plate type rapid sedimentation tank(DAT-150) Type: DAT-150 Inclined plate type rapid sedimentation tank
Inclined plate type rapid sedimentation tank(DAT-200) Type: DAT-200 Inclined plate type rapid sedimentation tank

Spec.		DAT-5	DAT-10	DAT-20	DAT-35	DAT-50	DAT-75	DAT-100	DAT-150	DAT-200
Spec.		Model
Capacity (m³/hr)		3~5	7~10	16~20	30~35	45~50	65~75	85~100	130~150	160~200
Sloping plate area(m²)		8	15	30	53	75	105	140	210	280
Scraper power(HP)		1/4	1/2	1/2	1/2	3/4	3/4	3/4	1	1
Reference machine dimensions(mm)	L	1600	2400	3000	3300	3500	4000	4500	5000	6300
	W	1000	1300	1500	1700	2000	2500	2500	3500	2500
	H	1800	2500	3500	3700	4000	4000	4000	4000	4500
