Automatic continuous flow sand bed filter equipment SD Series(SDD-30)
Type: SDD-30 (Multiple sets of parallel type))
Multiple sets of parallel Type
Usages:
- Wastewater primary sedimentation, secondary sedimentation, final sedimentation, and floating water treatment: medium water recovery filtration, municipal sewage discharge, and commercial sewage discharge.
- Industrial water treatment: surface water purification, groundwater purification, reservoir lake purification.
- Recycled water treatment: Cooling water circulation culture water filtration landscape water filtration
- Drinking water treatment: desalination treatment, surface water purification, groundwater purification, reservoir lake purification
- The process liquid is used to remove the slag, and the process liquid is filtered and recovered.
Machine outline diagram
Standard specifications (Contact for customized)
|
|
SDD-30 |
| Treatment Capacity (m³ /hr) | 18~30 |
| Filter area (m²) | 3 |
| Air stripping sand washing room group | 2 |
| Referance dimension(mm) |
|
| L |
Depending on the arrangement of the site |
| W | Depending on the arrangement of the site |
| H1 | 3000 |
| H2 | 4000 |
| Reference weight (kgs) | 13680 |
Remarks：
- S.S. Concentration Varies: The treatment capacity may differ depending on particle size and concentration changes.
- The specification is accepted outside the specification, and the company reserves the right to design changes
- Please request the actual installation dimension drawing before ordering
